250L Foldable Retail Display Unit

RDU

VideoBrochuresSpecifications

Inquiry

No need for repacking.One-stop from farm to supermarket.RDU can go straight from farm to supermarket without unpacking and repacking, reducing labor, storage space and packaging waste along the way. Quick and easy to replace in fresh produce departments, saving you time and money.

01Farm to load and transport.

02Supermarket

Combined functions.Perfect for display unit.Our RDU is designed with medium space for the fresh, perfect crates to display and attract consumers in supermarket on wheels.It can offer superior durability, hygiene and sustainability than the disposable packaging.

Four sides of RDU are designed with drop doors that can be opened and closed independently, easy access for customers. The strong visual impact helps deliver an improved shopping experience and encourages consumption.

A4-sized card holders on four sides, allowing retailers to display product information. Large printed areas on each side allow retailers to tailor own promotion ads.

All parts are connected by new hinges for easy assembly and disassembly. They make it easy to maintain and repair, thus improving work efficiency and reducing costs.

Stacking compatibility.Flexible combination.RDU is with high stack compatibility, no matter with the same RDU or reusable plastic crates (RPC), you can stack what you like to attract more consumers.

Stack with RPC.

Stack with RDU.

Double smooth surface.New process New experience.

Robust and durable.RDU’s ;side panels and base are both injection-molded with high-strength plastics Coupled with the innovative welding process, the product is designed with double smooth surfaces, robust and durable, allowing it to withstand accidental bumps and impacts.

Easy Cleaning.Thanks to the RDU’s double smooth surfaces , making cleaning and disinfection easy and quick.

RDUs foldability has greatly reduced the storage space and cost of return transport From farm to market, from farm to pre-warehouse, it is a one-stop logistics packaging solution or fresh products, and an ideal option for circulation and sharing.

Braking system, steady and safe. The RDU is designed with an innovative brake system on base, which makes braking extremely easy and convenient.

Worry-free Pulley Design. The RDU's pulleys are coated by rubber, with an outer layer of wear-resistant and noiseless shock-absorbing materials, which reduces bumps during transportation and provides better protection to the goods inside. The new caster design also stop threads, hair and other foreign objects from getting caught, reducing the costs of repair and replacement.

Anti-slip Base, For Extra Stability. 4L shaped anti-slip sheets on the bottom of the base sit perfectly on the forklift arms during transportation from the front or the side, preventing slipping during re-location and helping to eliminate safety hazards.

User-friendly design.RDU wheeled base.

High reliability.Internationally authoritative certifications, robust beyond imagination .

RDU has passed the general simulation performance test for packaging (ISTA-3E) and the D4169 - 08 Performance Testing of Shipping Containers and Systems by the International Safe Transit Association (ISTA) and the American Society for Testing and Materials (ASTM) respectively. Its product reliability and high quality are well-proven.*

Stacking compressionPlace in the center of the pressure platform, and pressurize F=Wts(S-1)xFxJ for 1 hour, where Wt is the total weight of a single full-load crate, S is the number of layers, F is the safety factor=3, and J is the gravity constant=9.8N/kg.

Rotational edge dropLift one long side edge or one short side edge by 200mm, drop 3 times respectively.

Four-side ImpactFinal velocity 1.22m/s, set a backstop with a cross-sectional area of 100×100mm at the footing of the impact wall.

Random vibrationTwo-layer stacking, level II: set Grms=0.52 and perform 120min random vibration test at 1-200Hz; level I: set Grms=0.73 and perform 120min random vibration test at 1-200Hz.

Environmental treatment – high low temperatureKeep for 72 hours at 50℃; keep for 72 hours at -20℃.

Footing ImpactInstall simulated forks on the impact wall, impact the middle footing and side footing once each, at a final velocity of 0.91m/s, on long and short sides once each.

RDU

Unit load of 250Kg

One-stop from farm to market

Staking compatibility

Drop doors on 4 sides

Ad card holders on four side

Double smooth surfaces

Optional wheeled or pallet base

CHECK THE TECHNICAL DATA

Inquiry

Do you want the bulk container with larger volume and heavy-duty capacity? For the large amount fruits & vegetables, such as harvesting or food processing. HOREN’s heavy-duty bulk container KF975 is specifically designed with unit load of 600kg, to increase efficiency and reduce waste for growers and packers.

FLC KF975

All the data on this website is provided by HOREN unless otherwise stated. *Full load: Only when the liquid density ≤ 1.35g/cm³. *High reliability test: All tests are tested at HOREN’s standard labs in simulation of the conditions required by ISTA and ASTM. *Traditional non-foldable IBC: Non-foldable plastic IBC tanks in general on the market with dimensions of 1200x1000x1145mm. *Regular plastic foldable IBC: IBCs on the market under Asian and European standards and with dimensions of 1200x1000x1140mm and volume of around 1000L. Thus IBC OF330, with a volume of 1249L, is about 25% larger. *Two-thirds: The volume of a folded IBC is approximately 1/3 of that when unfolded. So compared with a non-foldable container of the same size, 2/3 of the storage space is saved for return transport. *Three-quarters: The volume of a folded IBC OF330 is approximately 1/4 of that when unfolded. So compared with a non-foldable container of the same size, 3/4 of the storage space is saved for return transport. *Service life of up to 10 years: Measured in accordance with the limited conditions in HOREN’s standard labs. *TE pin: Available upon request and purchase. *Heater pad: Available upon request and purchase. *7.6:1: The ratio of the volume of an erected KingKong RPC to that when folded is approximately 7.6:1. *31%: Obtained upon measurement of multiple products under the same conditions of compression test in HOREN’s standard labs. *No Crate Change: Goods stored in HOREN’s crates can be directly transported from farm or place of origin to market for display and sale, without the need to change to new crates. *0.1%: In HOREN’s standard lab environment, 1000kg of 300,000-cP viscous liquid, after being discharging, leaves residues weighing <1kg. *Hands-free: After RRS and liner are installed, no more manual operation is needed during the discharge process. *Folding ratio 3:1: The ratio of the volume of an erected FLC KF975 to that when folded is approximately 3:1.
